Illustration: three concentric containment seals closing around a glowing alarm core

Engineering — Reference Implementation

SOAR Incident Containment Playbook

Spec1 min read

Purpose: Automated 3-tier incident containment for critical SIEM alerts — session eviction via Redis, Smart-ID/eIDAS identity anchor lock, and FIDO2 device quarantine with sub-second enforcement.

Version: 1.0.0 | Last Updated: 2026-06-28 Dependencies: redis-challenge-pipeline-docker.md (ZtaRedisPipelineManager), siem-logging-pipeline.md (ztaLogger, logSecurityEvent)

Following NIS2 Article 21 directives for proactive incident mitigation, this script acts as an automated SOAR playbook. When triggered by a SIEM alert, it coordinates with the components built in the previous steps to execute a 3-tier automated containment strategy:

Evict Active Sessions: Writes directly to the ZtaRedisPipelineManager to invalidate short-lived tokens across all Envoy API Gateways within seconds.
Lock User Identity Anchor: Calls the SK ID Solutions Smart-ID/Mobile-ID administrative APIs to temporarily suspend authentication capability.
Quarantine the Hardware Device: Updates the central zero-trust engine to reject the specific WebAuthn/FIDO2 authenticator (device_id).

1. Production SOAR Containment Script

typescript

import { ZtaRedisPipelineManager } from './ZtaRedisPipelineManager';
import { ztaLogger } from './ZtaLogger';
import axios from 'axios';

interface SiemAlertPayload {
  alert_id: string;
  trigger_reason: 'REPLAY_ATTACK_DETECTED' | 'MASS_REVOCATION_ANOMALY';
  target_user_id: string;
  target_session_id: string;
  target_device_id: string;
  source_ip: string;
  associated_challenge: string;
}

export class ZtaAutomatedResponsePlaybook {
  private redisPipeline: ZtaRedisPipelineManager;
  private SMART_ID_ADMIN_API = process.env.SMART_ID_ADMIN_API || '';
  private SMART_ID_AUTH_TOKEN = process.env.SMART_ID_API_AUTH_TOKEN;

  constructor() {
    if (!this.SMART_ID_ADMIN_API) throw new Error('FATAL: SMART_ID_ADMIN_API environment variable is required');
    if (!this.SMART_ID_AUTH_TOKEN) throw new Error('FATAL: SMART_ID_API_AUTH_TOKEN environment variable is required');
    this.redisPipeline = new ZtaRedisPipelineManager();
  }

  /**
   * Main orchestrator executed immediately when SIEM pushes an alert webhook
   */
  public async executeIncidentContainment(alert: SiemAlertPayload): Promise<void> {
    ztaLogger.warn('SOAR: Initiating automated containment playbook.', {
      alert_id: alert.alert_id,
      user_id: alert.target_user_id,
      session_id: alert.target_session_id
    });

    try {
      await this.redisPipeline.connect();

      // --- TIER 1: EVICT SESSIONS (Gateway Enforcement) ---
      // Invalidate the session instantly in the Redis layer read by the Envoy gRPC auth service
      // Set TTL to 1 hour (3600s) to completely outlast any active access tokens
      await this.redisPipeline.revokeSession(alert.target_session_id, 3600);

      // Blacklist the compromised FIDO2 hardware authenticator device ID across the fabric
      await this.redisPipeline.revokeDevice(alert.target_device_id, 86400); // 24-hour quarantine

      ztaLogger.info('SOAR Tier 1: Distributed Redis revocation vectors written.', {
        user_id: alert.target_user_id,
        device_id: alert.target_device_id
      });

      // --- TIER 2: SUSPEND IDENTITY ANCHOR (Smart-ID / eIDAS Layer) ---
      await this.lockSmartIdAccount(alert.target_user_id, alert.alert_id);

      // --- TIER 3: NOTIFY SECURITY OPERATIONS (Incident Logging) ---
      this.emitNis2ComplianceLog(alert);

    } catch (criticalError: any) {
      ztaLogger.error('SOAR CRITICAL: Automated playbook execution failed or partially executed.', {
        error: criticalError.message,
        alert
      });
      // In production, route to on-call engineer paging system (PagerDuty/Opsgenie API) here
    } finally {
      await this.redisPipeline.disconnect();
    }
  }

  /**
   * Interacts with SK ID Solutions / Smart-ID infrastructure to suspend the user identity account
   */
  private async lockSmartIdAccount(userId: string, alertId: string): Promise<void> {
    if (!this.SMART_ID_AUTH_TOKEN) {
      ztaLogger.error(
        'SOAR Configuration Error: Missing SMART_ID_API_AUTH_TOKEN. Skipping downstream anchor lock.'
      );
      return;
    }

    try {
      const response = await axios.post(
        `${this.SMART_ID_ADMIN_API}/users/${userId}/suspend`,
        {
          reason: `Automated ZTA Isolation: MitM Replay Threat detected under SIEM alert ${alertId}`,
          requested_by: 'SOAR-Orchestrator-Service',
          reference_incident: alertId
        },
        {
          headers: {
            'Authorization': `Bearer ${this.SMART_ID_AUTH_TOKEN}`,
            'Content-Type': 'application/json'
          },
          timeout: 4000 // Tight 4s boundary to prevent playbook hangs
        }
      );

      if (response.status === 200 || response.status === 204) {
        ztaLogger.info('SOAR Tier 2: Smart-ID/eIDAS authentication profile locked successfully.', { user_id: userId });
      }
    } catch (apiError: any) {
      ztaLogger.error('SOAR Tier 2 Error: Smart-ID administrative lock call failed.', {
        error: apiError.message,
        user_id: userId
      });
      throw apiError; // Escalate up to primary handling layer
    }
  }

  /**
   * Outputs the immutable, structured telemetry trace needed for NIS2 post-incident investigations
   */
  private emitNis2ComplianceLog(alert: SiemAlertPayload): void {
    ztaLogger.info('SOAR Containment logging complete. Mitigated attack vectors preserved for forensic analysis.', {
      regulatory_tags: ['NIS2_ART_21_INCIDENT_RESPONSE', 'EU_AI_ACT_CONTAINMENT'],
      event_type: 'AUTOMATED_MITIGATION_COMPLETED',
      remediation_actions: [
        'ENVOY_SESSION_EVICTION',
        'FIDO2_DEVICE_QUARANTINE',
        'SMART_ID_ANCHOR_SUSPERSION'
      ],
      mitigated_threat_metadata: {
        isolated_user: alert.target_user_id,
        isolated_session: alert.target_session_id,
        isolated_device: alert.target_device_id,
        attacker_ip: alert.source_ip,
        consumed_challenge: alert.associated_challenge
      },
      audit_status: 'READY_FOR_NATIONAL_COMPETENT_AUTHORITY_REVIEW'
    });
  }
}

2. Microservice Deployment Integration (Webhook Controller)

Wire the handler into an Express/Fastify endpoint configured to receive authenticated webhook payloads securely exported by the Splunk/ELK alert cluster.

typescript

import express from 'express';
import { ZtaAutomatedResponsePlaybook } from './soar_containment_playbook';

const app = express();
app.use(express.json());
const playbook = new ZtaAutomatedResponsePlaybook();

app.post('/api/v1/soar/webhook-trigger', async (req, res) => {
  // Validate incoming webhook authorization (token verification, IP restrictions)
  const authHeader = req.headers.authorization;
  if (authHeader !== `Bearer ${process.env.SIEM_WEBHOOK_SECRET}`) {
    return res.status(401).end();
  }

  const alertPayload: SiemAlertPayload = req.body;

  // Fire-and-forget playbook invocation to send HTTP 202 accepted response immediately to SIEM
  playbook.executeIncidentContainment(alertPayload);

  return res.status(202).json({ status: 'Processing containment instructions.' });
});

app.listen(3000, () => console.log('SOAR Webhook Ingestion Engine Online.'));

Playbook Properties & Incident Lifecycle

Sub-Second Enforcement Edge: Because the Envoy External Authorization service queries the high-speed Redis cluster on every inbound API or gRPC request, when this playbook executes revokeSession(), the attacker's hijacked bearer token becomes invalid across the global cloud infrastructure on their next request.
Preventing Attacker Self-Recovery: An attacker possessing a hijacked session might attempt to immediately re-authenticate via a browser prompt. By placing a programmatic administrative hold on the user's Smart-ID/Mobile-ID anchor profile (Tier 2), the system blocks the user's automated account recovery and enrollment vectors until a human security analyst performs verification.

References

[1] https://www.smart-id.com/smart-id-plus/ [2] https://www.skidsolutions.eu/news/smart-id-experience-the-next-generation-of-secure-authentication-now/ [3] https://openid.net/specs/openid-caep-specification-1_0.html [4] https://www.envoyproxy.io/docs/envoy/latest/configuration/http/http_filters/ext_authz_filter
