CAEP/SSF gRPC Implementation & eIDAS Audit Trail ​

Spec2 min read

Purpose: Go-based Envoy ExtAuthz gRPC service for CAEP/SSF continuous access evaluation, OID4VC/EUDI Wallet schema mappings, and NIS2/EU AI Act compliant cryptographically chained audit trail.

Version: 1.0.0 | Last Updated: 2026-06-28 Dependencies: redis-challenge-pipeline-docker.md (Redis key patterns), webauthn-server-validation-backend.md (JWT claims structure)

1. gRPC & API Gateway Implementation for CAEP/SSF ​

To move past point-in-time authentication, the API Gateway (e.g., Envoy) serves as the Policy Enforcement Point (PEP), checking token validity against a high-speed Redis cluster, while an Asynchronous SSF Receiver updates token states in real-time.

text
 [Threat Signal] ---> [SSF Receiver Hub] ---> [Redis Cluster] <--- [Envoy Auth gRPC API]
   (EDR / IdP)        (Invalidates session)    (Blacklist state)     (Intercepts inbound RPC)

Envoy External Authorization (ExtAuthz) gRPC Service ​

This Go implementation intercepts gRPC calls, parses the short-lived access token, checks the global Redis state for SSF revocations, and extracts metadata.

go
package main

import (
    "context"
    "errors"
    "net"
    "strings"
    "time"

    corev3 "github.com/envoyproxy/go-control-plane/envoy/config/core/v3"
    authv3 "github.com/envoyproxy/go-control-plane/envoy/service/auth/v3"
    typev3 "github.com/envoyproxy/go-control-plane/envoy/type/v3"
    "github.com/golang-jwt/jwt/v5"
    "github.com/redis/go-redis/v9"
    "google.golang.org/genproto/googleapis/rpc/status"
    "google.golang.org/grpc"
    "google.golang.org/grpc/codes"
)

type AuthServer struct {
    rdb         *redis.Client
    tokenKeyFunc jwt.Keyfunc
}

type CustomClaims struct {
    TenantID string `json:"tid"`
    DeviceID string `json:"did"`
    jwt.RegisteredClaims
}

func (s *AuthServer) Check(ctx context.Context, req *authv3.CheckRequest) (*authv3.CheckResponse, error) {
    // 1. Extract Bearer Token from HTTP/gRPC metadata
    headers := req.GetAttributes().GetRequest().GetHttp().GetHeaders()
    authHeader := headers["authorization"]
    if authHeader == "" {
        return unauthenticatedResponse("Missing authorization token"), nil
    }

    tokenStr := strings.TrimPrefix(authHeader, "Bearer ")

    // 2. Parse and validate JWT signature + standard claims before trusting payload data
    var claims CustomClaims
    parsedToken, err := jwt.ParseWithClaims(
        tokenStr,
        &claims,
        s.tokenKeyFunc,
        jwt.WithValidMethods([]string{"RS256", "ES256"}),
        jwt.WithIssuer("https://enterprise.eu"),
        jwt.WithAudience("https://enterprise.eu"),
        jwt.WithLeeway(30*time.Second),
    )
    if err != nil || !parsedToken.Valid {
        return unauthenticatedResponse("Invalid token"), nil
    }
    if claims.ID == "" || claims.Subject == "" || claims.DeviceID == "" || claims.TenantID == "" {
        return unauthenticatedResponse("Token missing required claims"), nil
    }

    // 3. CAEP/SSF Check: Query Redis for session/device invalidation status
    // Keys are pushed to Redis by the SSF Receiver asynchronously
    isRevoked, err := s.rdb.Exists(ctx,
        "revoked:session:"+claims.ID,
        "revoked:device:"+claims.DeviceID,
    ).Result()
    if err != nil || isRevoked > 0 {
        return &authv3.CheckResponse{
            Status: &status.Status{Code: int32(codes.PermissionDenied)},
            HttpResponse: &authv3.CheckResponse_DeniedResponse{
                DeniedResponse: &authv3.DeniedHttpResponse{
                    Status: &typev3.HttpStatus{Code: typev3.StatusCode_Forbidden},
                    Body:   "Access denied: Session or device revoked by security continuous evaluation",
                },
            },
        }, nil
    }

    // 4. Inject validated claims downstream into internal microservices
    return &authv3.CheckResponse{
        Status: &status.Status{Code: int32(codes.OK)},
        HttpResponse: &authv3.CheckResponse_OkResponse{
            OkResponse: &authv3.OkHttpResponse{
                Headers: []*corev3.HeaderValueOption{
                    {Header: &corev3.HeaderValue{Key: "x-user-id", Value: claims.Subject}},
                    {Header: &corev3.HeaderValue{Key: "x-tenant-id", Value: claims.TenantID}},
                    {Header: &corev3.HeaderValue{Key: "x-device-id", Value: claims.DeviceID}},
                },
            },
        },
    }, nil
}

func unauthenticatedResponse(msg string) *authv3.CheckResponse {
    return &authv3.CheckResponse{
        Status: &status.Status{Code: int32(codes.Unauthenticated)},
        HttpResponse: &authv3.CheckResponse_DeniedResponse{
            DeniedResponse: &authv3.DeniedHttpResponse{
                Status: &typev3.HttpStatus{Code: typev3.StatusCode_Unauthorized},
                Body:   msg,
            },
        },
    }
}

Shared Signals Framework (SSF) Event JSON (RFC 9493 / CAEP) ​

When an endpoint protection agent (EDR) detects an anomaly, it publishes this standard payload to the SSF receiver endpoint to update the Redis blocklist shown above:

json
{
  "iss": "https://enterprise.eu",
  "jti": "caep-8743-219847129",
  "iat": 1782618240,
  "aud": "https://enterprise.eu",
  "events": {
    "https://openid.net": {
      "subject": {
        "format": "iss_sub",
        "iss": "https://enterprise.eu",
        "sub": "usr_01J2X7"
      },
      "current_status": "non-compliant",
      "previous_status": "compliant",
      "device": {
        "format": "opaque",
        "id": "dev_mac_99214812"
      },
      "reason": "EDR detected active unmitigated malicious payload execution"
    }
  }
}

2. eIDAS 2.0 EUDI Wallet Credential Schema Mapping ​

The integration of the European Digital Identity Wallet (EUDI) relies on W3C Verifiable Credentials using the OpenID for Verifiable Presentations (OID4VP) framework over mobile-driving-license (mDL) ISO/IEC 18013-5 or W3C JSON-LD profiles.

Selective Disclosure Mapping Architecture ​

To adhere strictly to GDPR Data Minimization, the Relying Party must request only precise claims instead of the full identity payload.

json
{
  "id": "eudi_wallet_legal_verification_request",
  "input_descriptors": [
    {
      "id": "eu.europa.ec.eudiw.pid.1",
      "format": {
        "mso_mdoc": {
          "alg": ["ES256", "ES384"]
        }
      },
      "constraints": {
        "fields": [
          {
            "path": ["$.eu.europa.ec.eudiw.pid.1.family_name"],
            "intent_to_retain": true
          },
          {
            "path": ["$.eu.europa.ec.eudiw.pid.1.given_name"],
            "intent_to_retain": true
          },
          {
            "path": ["$.eu.europa.ec.eudiw.pid.1.age_over_18"],
            "intent_to_retain": false
          },
          {
            "path": ["$.eu.europa.ec.eudiw.pid.1.issuing_country"],
            "intent_to_retain": true
          }
        ]
      }
    }
  ]
}

Token Schema Translation Pattern ​

Once the wallet presents the data, the identity fabric normalizes and injects it into standard OAuth2/OIDC claims formats used by internal enterprise resource servers.

json
{
  "iss": "https://enterprise.eu",
  "sub": "eudi|EU-EST-39102140124",
  "aud": "https://enterprise.eu",
  "exp": 1782618540,
  "identity_assurance": {
    "assurance_level": "high",
    "framework": "eidas2",
    "verification_method": "eudi_wallet",
    "attestation_authority": "Estonian Information System Authority (RIA)"
  },
  "verified_claims": {
    "claims": {
      "given_name": "Mari",
      "family_name": "Tamm",
      "age_over_18": true,
      "nationality": "EE"
    }
  }
}

3. NIS2 & EU AI Act Audit Trail Architecture ​

This architecture addresses two distinct legal demands: NIS2 Article 21 (tamper-proof event logs for incident reporting) and EU AI Act Article 12 (traceability and automated logging of high-risk AI/ML systems).

text
 [Security Events] ---> [Log Processor] ---> [Asymmetric Signature Generation] ---> [Write-Once-Read-Many (WORM)]
                                                      |
                                             [Local TPM 2.0 / HSM]

Log Architecture Strategy ​

  1. Cryptographic Chaining: Every log record contains a hash of the preceding record, forming an immutable append-only ledger directly within the SIEM infrastructure.
  2. Hardware-Backed Signatures: The log signing application utilizes a hardware security module (HSM) or cloud KMS with an asymmetric key to sign log batches hourly.
  3. Data Anonymization: AI risk scoring input flags (e.g., behavioral telemetry) are stored stripped of non-essential PII to meet GDPR rules while retaining technical audit integrity.

Production JSON Audit Schema (NIS2 + EU AI Act Compliant) ​

This production event entry maps data from an adaptive AI authentication risk challenge followed by a high-assurance FIDO2 resolution.

json
{
  "timestamp": "2026-06-28T00:04:15.124Z",
  "event_id": "evt_9912A-FF31-409B",
  "sequence_number": 88124501,
  "previous_record_hash": "e3b0c44298fc1c149afbf4c8996fb92427ae41e4649b934ca495991b7852b855",
  "regulatory_context": {
    "governing_mandates": ["NIS2_ART_21", "EU_AI_ACT_ART_12"],
    "system_classification": "High-Risk AI Access Control Safeguard"
  },
  "actor": {
    "sub": "usr_01J2X7",
    "device_id": "dev_mac_99214812",
    "tenant_id": "ten_eu_core_01"
  },
  "ai_risk_engine_telemetry": {
    "model_version": "ueba-core-v4.2.1",
    "evaluation_mode": "deterministic-fallback-enabled",
    "inputs_processed": {
      "typing_cadence_variance": 0.41,
      "network_velocity_km_h": 1200.0,
      "request_path_anomaly_score": 0.89
    },
    "risk_classification_output": "HIGH_RISK_SUSPECTED_SESSION_HIJACK",
    "action_triggered": "STEP_UP_AUTHENTICATION_REQUIRED",
    "human_oversight_override_capability": {
      "kill_switch_active": false,
      "bypass_applied": false
    }
  },
  "mitigation_resolution": {
    "step_up_mechanism": "WebAuthn_FIDO2_User_Verification",
    "challenge_id": "chal_88419241920",
    "status": "SUCCESSFUL_CRYPTOGRAPHIC_VERIFICATION",
    "authenticator_data": {
      "aaguid": "adce0002-35bc-c60a-2b7b-40b2fed21711",
      "user_verification_indicator": 1,
      "signature_algorithm": "ES256"
    }
  },
  "integrity_seal": {
    "signing_key_arn": "arn:aws:kms:eu-central-1:YOUR_ACCOUNT_ID:key/nis2-log-signer-key",  <!-- PLACEHOLDER: Replace account ID -->
    "signature": "MEYCIQCc1R8g4h6...[Truncated Base64 Cryptographic Signature]..."
  }
}

References ​

[1] https://openid.net/specs/openid-caep-specification-1_0.html [2] https://www.envoyproxy.io/docs/envoy/latest/configuration/http/http_filters/ext_authz_filter [3] https://github.com/envoyproxy/go-control-plane [4] https://redis.io/docs/latest/develop/clients/go/ [5] https://eu-digital-identity-wallet.github.io/eudi-doc-architecture-and-reference-framework/latest/architecture-and-reference-framework-main/ [6] https://www.rfc-editor.org/rfc/rfc9493.html
